Ohlins HO 047 STX 36 Rear Shock – Honda Grom '20-25

Suspension / OHLINS

Share

$658.90

DAL: 0 HOU: 0 WEB: 14

Quantity:

123 Add To Cart

Earn $32.94 in UBD Bucks

We ship nationwide!

Questions?
Speak to one of our experts today:
469-890-0123

Brand:

OHLINS

SKU:

1310-2264

Description:

Ohlins HO 047 STX 36 Rear Shock – Honda Grom ’20–25

Product Overview

The HO 047 is an Öhlins STX 36 rear shock absorber for the Honda Grom. It is a high-pressure, gas-charged monotube shock with an external hose-mounted reservoir, built on Öhlins’ STX technology. Rebound damping, compression damping and spring preload are all adjustable, so it can be set up for rider weight and riding style. It is for Grom riders over 80 kg (176 lb); lighter riders should look at the HO 424.

Key Technology & Design

• STX Monotube Design — A single-tube shock with a 36 mm piston and an external hose-mounted reservoir.
• Gas Charged — High-pressure nitrogen gas charge.
• Adjustable Damping — Rebound and compression damping are both adjustable.
• Adjustable Preload — Preload is set with a tool, which is included.
• Build — Hard-anodized, precision CNC-machined components with a low-friction shaft and seal head design.
• Serviceable — The shock is fully serviceable and repairable.

Specs

Type	Coilover monotube rear shock absorber
Model	STX 36
Mounting position	Rear
Reservoir	External, hose-mounted
Bore size / piston diameter	36 mm
Damping method	Gas charged
Adjustment	Rebound damping, compression damping, spring preload (with tool)
Spring rate	120 lb/in (linear)
Extended length	9.61 in
Material	Steel
Color / finish	Chrome / yellow
Rider weight	Over 80 kg / 176 lb
Manufacturer part number	HO 047

Fitment

Year(s) — Make / Model

2020	Honda Grom
2022–2025	Honda Grom (incl. Grom RR 2022–2023)

California Prop 65: this product can expose you to chemicals including nickel. See www.p65warnings.ca.gov.
